-5-
3
X-axis Aluminum Profile
Hex Socket Head Bolt M5*25
Y-L AXIS
Y-R AXIS
4 8
Insert the nut into
the profile, tighten
the screws
Insert the nut into
the profile, tighten
the screws
Insert the nut into the
profile, tighten the
screws
Insert the nut into
the profile, tighten
the screws
4x
2x
