BIOS TBL Enable Jumper: TBL_EN(optional)
If the BIOS failed to be flashed in conventional flash
BIOS process, the system can not boot. You will
have no such worry when using the BIOS TBL
jumper which is used to protect BIOS “Top Boot
Block”. By using this function, the system still can
boot even if the falsh BIOS fails and show some
information to recover the BIOS. To utilize this
function, you just leave this jumper as short pin 2
and pin 3 with the jumper cap.
Disable
(Default)
21 3
Enable
TBL_EN
21 3
