1
3
1-3 Back Side View
1-4 Bottom View
No. Name Description
1 USB 2.0 Ports Connects to USB devices
2 Display Output Port Connects to display device
3 HDMI Port Connects to HDMI audio and video
4 Network Port Standard RJ-45 network port
5
Line Out and S/PDIF Out Port
Connects to powered analog speakers or record-
ing devices with optical connectors(3.5mm jack)
6 Power Input Port Connects to the power adapter
4
3 652
1
No. Name Description
1 Sheet Metal NETDVD(optional accessary) or Magnet-Metal-Feet can mag-
netize them to seat rmly
There are four Magnet-Metal-Feet in the package. Just align them to the sheet metal
on the bottom, then they can magnetize the NETTOP easily. The feet can seat and
protect NETTOP when it is placed on the tabletop.
C
A
U
T
I
O
N
!
1
