Exit RAID BIOS
1. Take TryRAID5 as an example, select “4. Exit” in main menu and press <Enter>.
The screen displays :
2. Press <Y> to exit Intel
®
Matrix Storage Manager program. The system will reboot.
3. Shut down the computer, remove WD hard disk, and we will continue for Windows
OS installation. If you do not remove irrelevant WD hard disk, Windows may detect
it during the installation, and you could be confused.
4. Remove any diskette from oppy drive.
5. Restart computer to start Windows installation.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Exit
RAID Volume : * = Data is Encrypted
ID Name Level Stripe Size Status Bootable
0 TryRAID5 RAID5(Parity) 64KB 465.8GB
Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Non-RAID Disk
2 Maxtor 6L250S0 L50SKP4G 232.9GB
Member Disk(0)
4 ST3320620SV 9QF4YJGQ 298.1GB
Member Disk(0)
5 ST3300831AS 3NF02XH2 279.5GB
Member Disk(0)
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
Are you sure you want to exit? (Y/N):
[ CONFIRM EXIT ]
