1-1 Product Specications
CPU Support LGA775 socket Intel
®
CPU:
Intel® Core™2 Quad, Core™2 Extreme, Core™2 Duo, Pentium® Dual-Core,
Celeron Dual-core, Celeron processors
Front Side Bus 1333/1066/800MHz FSB
Chipset North Bridge: Intel
®
P45
South Bridge: Intel
®
ICH10R (P45A-S)
Intel
®
ICH10 (P45A)
Memory 4 x 240-pin DDR2 DIMM sockets
Support up to 8GB of system memory
Dual channel DDR2 1066(oc*)/800/667MHz architecture (oc*: Overclocking)
Audio Realtek 8-channel audio chip
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF out
Support Jack-Sensing function
LAN Realtek 10/100/1000Mb/s LAN chip
Expansion Slots 2 x PCI Express x16 slots
2 x PCI Express x1 slots
2 x PCI slots
Onboard Serial ATA 6 x SATA connectors (Controlled by ICH10R/ICH10)
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
USB Support hot plug
Support up to 12 x USB 2.0 ports (4 rear panel ports, 4 onboard USB
headers supporting 8 extra ports)
Supports USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x Floppy disk drive connector
1 x IDE connector (Controlled by Jmicron361)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x NB fan header (4-pin)
1 x CD_IN connector
1 x Front Audio connector
1 x 1394a connector (P45A-S)
4 x USB 2.0 connectors (supporting 8 x USB devices)
6 x SATA connectors
1 x Front Panel connector
1 x IrDA connector
1 x Chassis intrusion alarm header
1 x Speaker connector
