Integrated Peripherals

► OnChip ATA Devices/OnBoard Devices/SuperIO Configuration/USB Configuration

Press <Enter> to go to relative submenu.

OnChip ATA Devices

► Configure SATA as

This item is used to set the operation mode of your SATA ports. Setting values are: [IDE];

[RAID]; [AHCI]; [Disabled].

[IDE] - This congures the SATA ports to support IDE mode.

[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.

[AHCI] - The Advanced Host Controller Interface (AHCI) specication describes the register

level interface for a Host Controller for Serial ATA. The specication includes a description of

the hardware/software interface between system software and the host controller hardware.

Integrated Peripherals

► OnChip ATA Devices

[Press Enter] Help Item

► OnBoard Devices

[Press Enter]

► SuperIO Conguration

[Press Enter] OnChip ATA Devices

► USB Conguration

[Press Enter]

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Press Enter]

OnChip ATA Devices

Configure SATA as [IDE]

Help Item

SATA#1 Conguration [Enhanced]

SATA#2 Conguration [Enhanced]

IDE Detect Time Out [35]

Marvell 6121 PATA and eSATA [eSATA + IDE] I IDE

RAID

AHCI

Disabled

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[IDE]

Options

Foxconn P55A User Manual
