Onboard calibration produces better results.
2. Compass Calibration
AYK-350 VTOL uses high sensitivity compass and it has to be re-calibrated when fly in a new place.
Enter the compass setting page and click”start” , hold the plane and rotate it in order to hit all directions
on a sphere to calibrate the compass, when it’s done, a new offset would be given to the flight controller,
and a reboot is necessary.
3. Radio Control Calibration
Calibrating each of the transmitter controls/channels is a straightforward process - simply move each of
the enabled sticks/switches through their full range and record the maximum and minimum positions.
FOXTECH AYK-350 User Manual
