FPI U31-NG2 - Faceplate Assembly

30
FPI U31-2 Gas Fireplace Insert
PARTS LIST
402-919 Complete Faceplate (Set) with Black Trim - Oversize
41) * Faceplate Side Right - Oversize
42) * Faceplate Top - Oversize
43) * Faceplate Side Left Assy-Oversize
402-534 Trims Pkg. - Oversize, Zero Clearance
44) * Faceplate Trim Right - Oversize
45) * Faceplate Trim Top - Oversize
46) * Faceplate Trim Left Assy - Oversize
400-917 Complete Custom Faceplate (Set)
71) * Faceplate Side Right - Custom
72) * Faceplate Top - Custom
73) * Faceplate Side Left - Custom
412-906 Complete Faceplate (Set) with Black Trim - Zero Clearance
81) * Faceplate Side Right - Zero Clearance
82) * Faceplate Top - Zero Clearance
83) * Faceplate Side Left Assy-Zero Clearance
402-534 Trims Pkg. - Zero Clearance
85) 836-203 Thermal Insulation - Top
400-939 Valve Access Faceplate
89) * Faceplate Side Left Assy
90) * Cover Plate - Valve Access
402-918 Complete Faceplate (Set) with Black Trim - Standard
91) * Faceplate Side Right - Standard
92) * Faceplate Top - Standard
93) * Faceplate Side Left Assy - Standard
402-532 Trims Pkg. - Standard
94) * Faceplate Trim Right - Standard
95) * Faceplate Trim Top - Standard
96) * Faceplate Trim Left Assy - Standard
402-933 Molded Faceplate Complete (Set)
141) * Faceplate Side Right - Molded
142) * Faceplate Top - Molded
143) * Faceplate Side Left Assy -Molded
144) 402-044 Mounting Bracket - Right
145) 402-045 Filler Bracket
146) 402-043 Mounting Bracket - Left
147) * Screw - #8 x 3/4" Pan Head
400-950 Hearth Trim 1" - Standard
320-940 Hearth Trim 1" - Oversize
400-926 Hearth Trim 2" - Standard
320-942 Hearth Trim 2" - Oversize
180) 400-928 Hearth Trim 4" - Standard
181) 320-944 Hearth Trim 4" - Oversize
400-959 Hearth Trim 6" - Standard
320-946 Hearth Trim 6" - Oversize
184) 410-525/01 Hearth Trim 4" - Zero Clearance
185) 904-569 Fan Speed Control Knob (120 V)
186) 904-586 Speed Control Knob c/w Spring Clip
187) 910-246 Burner ON/OFF Switch
188) 910-330 Fan Speed Control (120 V)
190) * Screw #8 x 1/2" Black self-tapping
191) * Screw #8 x 1/2" Brass self-tapping
199) 948-220 Hampton Logo Plate
*Not available as a replacement part.
Faceplate Assembly
Part # Description
