11
ENGLISH
Index
1. Safety warnings pag. 10
2. Description pag. 10
3. Installation and acquisition pag. 13
4. Programming pag. 14
5. Test pag. 18
6. Reset pag. 19
7. Technical specifications pag. 19
1 - SAFETY WARNINGS
The system must be installed by qualified operators, in compliance with current national and
local safety laws.
Installation warnings: In compliance with European Directive 1999/5/CE (R&TTE), the system
must be installed using devices, cables and accessories that comply with the requisites esta-
blished by the Directive for permanent installations. The installation of this product should be
performed in accordance with the installation instructions provided, in order to preserve the
operator from injury and product damage. The product must be installed in a dry environment
inside buildings.
Keep physically separate wires at very low voltage, including those of the battery, from the wi-
res to the mains voltage and / or from those of the telephone network.
To avoid damage to the device caused by electrostatic discharge, do not touch the antenna
without the guard cap and electronic components.
IMPORTANT: Only trained and authorised personnel are allowed to work on the system for the
connections as described in the instruction manual. In case of a malfunction, do not attempt to
repair the product as it would render the guarantee invalid. It is advisable to periodically check
that the alarm system is in perfect working order; however, a reliable electronic alarm system
does not prevent intrusion, theft, fire or other events but helps to reduce the risk of them oc-
curring.
CONFORMITY WITH EUROPEAN DIRECTIVES - Fracarro Radioindustrie SpA declares that the
product conforms to the essential requisites and other permanent provisions established by the
directive 1999/5/CE (R&TTE) and then CEI EN 60950 -1, ETSI EN 300 220 -2, ETSI EN 301 489 -
1, ETSI EN 301 489 -3.
2 - DESCRIPTION
TheMOD-WL16allowsthecreationofmixedsystems(wire–wireless),connectingupto16
devices of the Defender WL system to a DEFENDER HYBRID control panel through a bidirec-
tional radio connection. The information exchange between the MOD-WL16 module and the
control unit is made by a BUS connection. The module can interface with the indoor infrared
detectors and the magnetic detectors and also permits a radio connection with the outdoor
sirens and the outdoor infrared sensors.
Furthermore, the installation can be managed by the WL04TC remote control. The wire-radio
interface is compatible with all indoor and outdoor sensors, sirens and remote controls of the
WL series (TEATRO B-WL TEATRO M-WL, MB-WL, MM-WL, MB2-WL, MM2-WL, IRPET-WL,
TC5-WL, SEL-WL, IREX-WL, IR2EX-WL, TC4-WL, SEL04-WL, KEYBY-WL, HELPY-WL).
The device can be easily programmed by the T8N keypad or by a PC (with a MOD-USB).
