18
Prisma AL-12 PWM
Prisma AL-14 PWM
105
125
Celsius+ Prisma S24 & S36 Celsius+ Prisma S28
Specications
Type of Fan: PWM
Rated Voltage: 12V DC
Maximum Rated Input Current: 0.18 A
Max. Air Flow (@Zero Static Pressure): 103.9 CFM
Max. Air Pressure (@ Zero Air Flow): 2.38 mm H
2
O
Noise: 34.1 dB(A)
Max Speed: 1700 RPM
LED Input Voltage: 5V
LED Max. Rated Input Current: 0.30 A
Type of Fan: PWM
Rated Voltage: 12V DC
Maximum Rated Input Current: 0.18 A
Max. Air Flow (@Zero Static Pressure): 85.71 CFM
Max. Air Pressure (@ Zero Air Flow): 2.78 mm H
2
O
Noise: 32.7 dB(A)
Max Speed: 2000 RPM
LED Input Voltage: 5V
LED Max. Rated Input Current: 0.30 A
0
200
400
600
800
1000
1200
1400
1600
1800
2000
10 20 30 40 50 60 70 80 90 100
Speed (RPM) v.s. Duty cycleRPM
Duty cycle(%)
0
200
400
600
800
1000
1200
1400
1600
1800
10 20 30 40 50 60 70 80 90 100
Speed (RPM) v.s. Duty cycleRPM
Duty cycle(%)
