Fractal Celsius+ - Fan Specification

17
Fan Specication
Technische Daten / Spéci󰘰cations / Especi󰘰caciones / Speci󰘰kationer / Технические характеристики / 仕様 / 规范 / 規格
Dynamic X2 GP-12 PWM
Celsius+ Dynamic S24 & S36 Celsius+ Dynamic S28
Dynamic X2 GP-14 PWM
105
125
Specications
0
200
400
600
800
1000
1200
1400
1600
1800
2000
10 20 30 40 50 60 70 80 90 100
Speed (RPM) v.s. Duty cycleRPM
Duty cycle(%)
0
200
400
600
800
1000
1200
1400
1600
1800
10 20 30 40 50 60 70 80 90 100
Speed (RPM) v.s. Duty cycleRPM
Duty cycle(%)
Type of Fan: PWM
Rated Voltage: 12V DC
Maximum Rated Input Current: 0.2 A
Max. Air Flow (@Zero Static Pressure): 87.6 CFM
Max. Air Pressure (@ Zero Air Flow): 2.3 mm H
2
O
Noise: 32.2 dB(A)
Max Speed: 2000 RPM
Type of Fan: PWM
Rated Voltage: 12V DC
Maximum Rated Input Current: 0.25 A
Max. Air Flow (@Zero Static Pressure): 105.9 CFM
Max. Air Pressure (@ Zero Air Flow): 1.95 mm H
2
O
Noise: 33.7 dB(A)
Max Speed: 1700 RPM
