Additional Info
GPU LENGTH – MAX 326 mm
CPU Cooler
MAX 55 mm
GPU WIDTH
MAX 63 mm
CPU Clearance 70 63 55 [mm]
GPU Width 48 56 63 [mm]
GPU Height 137 137 137 [mm]
GPU Width 2.4 2.8 3.1 [slots]
Recommended max backplate width 4 mm
CPU Clearance 70 63 55 [mm]
GPU Width 48 56 63 [mm]
GPU Height 137 137 137 [mm]
GPU Width 2.4 2.8 3.1 [slots]
Recommended max backplate width 4 mm
