RM 2106 / 2112
24
Setup code Signicance Standard values Setting range
-5- Manual setting
of response
current
2.00 from 0.02 to 2 in steps of 0.01
-6- Relative value
of the stage
1.0 for each
switch output
Optional for each switch output the
value 0 to 16 in steps of 1.0
-7- Service --- Measuring (only the fundamental
frequency components):
- Active current
- Reactive current
- Apparent current
Table 1 Programmable values
The procedure for checking or reprogramming
the setting values is as follows:
■ Press the ”Select”(i) key to switch to
setup mode (approx. 6 seconds) until
the ”Setup Mode” LED (f) lights up.
”-1-” then appears on the display. This
number (setup code) shows which
variable is displayed and/or changed
(see Table 1).
■ The current setting alternates with the
setup code on the display.
■ By pressing ”Voltage THD” key (h) it
is possible to switch to the next highest
setting value. The highest setting value
is followed by the lowest setting value
again.
■ Pressing the ”Select” key briey switches
to the next setup code (see Table 1).
The setting value displayed can also be
changed as described above.
■ The control relay returns to automatic
regulatory mode if the ”Select” key is
held down (approx. 3 seconds).
