4. PORTABLE AND EASY TO USE
• The unit can be easily transported from one room to another.
• The air capacity is adjusted with three ventilation levels available.
• Installation by a qualied service is not required.
• All you need is to connect it to an electrical socket with parameters of 220-240V and 50Hz.
• The air outlet pipe may be stored in the unit during transport or with the air conditioner not operated at the moment.
• Do not connect the hot air pipe to any air ducts. It may cause the unit to sustain damage not covered with its warranty. Make sure that hot air ows
out freely from the outlet pipe.
• Do not extend the hot air pipe beyond its maximum length of 2 metres. If extended, the unit’s temperature cannot exceed 32°C. Otherwise, it may
cause the unit to sustain damage not covered with its warranty.
5. THIS DELIVERY SHOULD INCLUDE:
1 x Central unit
1 x Remote control
1 x Large at-headed pipe end
1 x Air discharge pipe 1.5 m, 15cm diameter
1 x Hot air pipe connector
1 x Window adapter
1 x Water discharge hose
6. UNIT DESCRIPTION
Control panel
Cold air outlet
Grip holes
Hot air outlet
Condenser air intake plus air lter
Evaporator air intake plus air lter
Power cable
Upper water drain valve
Lower water drain valve
Wheel casters
FRAL SUPER COOL FSC12H
PORTABLE AIR CONDITIONER
