Framery One
21. Rotate the front frame with door 180°.
Warning: Risk of injury and damage to property. Heavy object. Lift carefully.
Lifting requires a minimum of 2 people. The front frame with door weighs
approx. 86 kg (190 lbs)
Note: Make sure that the hooks on the door frame are directly above the slots
at the edge of the floor.
22. Install the guide pin set aside earlier.
Changing the door handedness
