FR
1
8
18
CARACTERISTIQUES
Encombrement
0÷152
280
598 - 898
175
ø 120
Min.
650mm
Min.
650mm
Hotte Type 45 50 55 60 70 80 90
L 448 498 548 598 698 798 898
Composants
f. Q.té Composants de Produit
1 1 Corps Hotte équipé de:Commandes, Lumière, Groupe Ventilateur,
Filtres
8 1 Grille orientée Sortie de l ’Air
20 1 Profil fermeture
Réf. Q.té Composants pour l ’installation
12a 4 Vis 4,2 x 44,4
12e 2 Vis 2,9 x 9,5
Q.té Documentation
1 Manuel d’instructions
12e
8
1
12a
20
