13
TO USE YOUR NEW FRANKE COOKTOP (GAS BURNERS ONLY)
PLEASE KEEP AND READ FOR FUTURE REFERENCE
1. Select the control knob corresponding to the gas burner you wish to use, press down and turn the knob to the position shown below.
NOTE: BURNERS WILL IMMEDIATELY BEGIN SPARKING VIA THE ELECTRONIC IGNITION SYSTEM WHEN ANY OF THE GAS CONTROLS ARE
DEPRESSED. IF THERE IS NO IGNITION SPARK THEN THE APPLIANCE MAY NOT HAVE THE POWER TURNED ON. CHECK THE POWER POINT
AND CONFIRM THE UNIT HAS POWER.
2.
Press and hold the control knob down firmly for a full 5 seconds to ensure the flame failure device engages. If the flame goes out after you release the
knob then the flame failure device did not engage – simply press down the knob firmly again turn to max position and keep pressing for a full 5 seconds.
MAXIMUM POSITION- WOK BURNER
CONTROLS
MAXIMUM POSITION-
A, B AND C BURNER
CONTROLS
ADJUSTMENT RANGE FOR
OUTER BURNER OPERATION-
WOK BURNER
ADJUSTMENT RANGE FOR
INNER BURNER OPERATION-
WOK BURNER
ADJUSTMENT RANGE FOR
BURNER OPERATION-
A, B AND C BURNERS
