Franklin Chef FIM1000 - Ice Storage Bin Attachment Method

8
REAR VIEW
The two holes are for attachment to the ice storage bin. See drawings below.
Typical installation of ice storage bin
Two connecting brackets are attached to the upper rear edge of the ice storage bin. Turn the
brackets up (180°) and use two screws to connect the main machine and ice storage bin.
Connecting
brackets
Rear of ice
storage bin
Drain
