Name
Battery
Motors
Size
Maxium load
30KGS/66LBS
1080*735*635mm / 42.52*29*25INCH
Speed
Charing time
Batteries of
Remote control
Age
Charger
DK-CA003
3-8km/h / 1.86-4.96MPH
8-12 hours
AAA battery 1.5V*2 (not including)
37-95 months
220V /110V
12V Output: DC12V1000MA or DC15V1000MA
24V Output: DC24V1000MA or DC28.8V 800MA
12V4.5AH / 12V7AH / 12V10AH / 12V14AH
24V5AH / 24V7AH
390#12V15000RPM(Driving motors)
550#12000RPM(Driving motors)
380#12V4800RPM(Steering direction changing motors)
555#24V12000RPM(Driving motors)
395#24V8000RPM(Steering direction changing motors)
Charging the Drive Battery:
IMPORTANT!
IMPORTANT! STEPS:
8 12
8 12
20
20
Before using the unit for the first time the battery needs to
be charged for at least
is depleted, recharge for
to
to
hours - no more than hours. Once battery
hours - no more than hours.
NOTE:
NOTE:
Check the drive battery and charger (supply
cord, connector) for wear and damage
before charging. Do not charge the battery if
damage has occurred. Only replace with the
same type and voltage rechargeable battery
and charger supplied by the manufacturer.
Only use the rechargeable battery (or
equivalent replacement) and charger sup-
plied with your vehicle.
Always turn power off and charge battery
after riding.
The drive battery should be charged when
depleted, or if not used regularly, once a
month. Failure to charge the battery as
directed will cause permanent damage to
the battery and will void the warranty.
1. Locate Charging Port.
2. Plug Charger plug into unit Charging
Port.
3. Plug Charger into Wall outlet.
4. When battery is fully charged, un-
plug charger from the wall outlet and
disconnect from charger port.
The charger may feel warm during
the charging. If excessively hot, unplug and
replace.
When charging, all functions are turned OFF.
This product has charging protection:
