6
Assembly
5. Install fix part of back supportive carriage
Install fix part of back supportive carriage onto the car body, and fix it
with 8 pcs of M4*12mm self-tapping locking screws.
6. Install rear wheels
a. Insert the back axle into the motors and car body. (Notes: Add 1 pc of
M12 gasket to the inside part of motor with 390# motors version)
b. Install rear wheel-M12 gasket-M10 locking screw-wheel cover onto the
back axle following the correct squence.
Rear wheel
M12 gasket
Wheel Cover
M10 Locking Screw
Back Axle
Rear Driving Motor R
Installation steps
