FPQ41 Superminor Issue 1 19
Before using the Superminor, make
sure the stand is on the floor and is
stable. It should be able to move freely
in the frame (section
4.7.1).
Figure 4-26: Select SUCK
Select SUCK on the Suck/Blow valve.
Make sure that the discharge valve on the return
hose is closed.
Figure 4-27: Discharge valve closed
Open the suction valve on top of the tank turret.
Press the green
I button of the power switch to
start the Superminor.
The Superminor suction will start straight away.
Use the tool to vacuum the coolant and debris.
Figure 4-28: Suction valve open
the tone of the motor changes.
the Superminor stops suction
because the float ball in the tank
acts as a safety mechanism. You
must empty the tank to restart
vacuuming.
When you have finished, press the red
O button
of the power switch controls to stop the
Superminor.
Remove the used filter and replace it with a clean
one (section 4.2).
Dispose of the waste products in accordance with
your company procedures.
Figure 4-29: Power switch
