FPQ41 Superminor Issue 1 15
4.5 Switching on and off
The power cable (1) and power switch (2) are
located at the handle end of the Superminor on
the motor pod.
The power cable can be wound around the
handles for storage.
Connect the power lead (1) to the power socket
on the wall.
Figure 4-15: Power switch location
Check the voltage rating of the
Superminor by looking at the rating
label. Make sure that you connect
the power lead to the correct supply.
To switch on, press the green I button.
To switch off, press the red
O button.
Figure 4-16: Power switch
The 3kW Superminor has a boost button next to
the power switch (Figure 4-17) which switches on
the third motor to bring the power up to 3kW.
To switch on the 3kW Superminor, press the
green I button as described above. This powers
the Superminor to 2kW. Press the Boost button
to reach full power of 3kW.
To switch off the 3kW Superminor, press the red
O button.
Figure 4-17: 3kW Superminor power
switch with boost button
