ACCESSORY INSTALLATION
Window Panel Kit (Optional Accessory)
The Window Panel Kit is an accessory which, when used with the Exhaust Duct Kit, will
increase cooling efficiency by directing warm air exhaust out a window and preventing
outside air from getting into the room.
1. Extend panels to fit in window opening. For vertical windows,
be sure cut-out is to the bottom.
2. To secure panels in place, install set screws into two smaller holes
on outer panel.
3. Locate two long, rubber weather strips. Hold flat side of weather
strips along outside of outer panel (with cutout). Slide weather
strips into rails on each side of outer panel.
4. Locate two short, rubber weather strips. Hold flat side of weather
strips along outside of inner panel. Slide weather strips into rails
on each side of inner panel.
5. Cut the two short, rubber weather strips to align with end of
inner panel. Use care when cutting weather strips.
6. Place Window Panel Kit into window opening. Close window
tightly against Window Panel Kit.
7. Install the outlet nozzle of the Exhaust Duct Kit into the cut-out
in the outer panel. The outlet nozzle fits tightly into the cut-out.
11
