57| AIRCRAFT FLIGHT MANUAL
FPV SYSTEM INSTALLATION
CAMERA
1. Remove the front closeout panel with a 2.0mm hex driver
2. Locate the FPV camera cable included in the ALTA 8 package
3. Pass the FPV cable through the closeout panel grommet and connect to the
mating FPV camera lead inside ALTA 8. Connect the other end directly to the
camera
4. Replace front closeout panel.
