56| AIRCRAFT FLIGHT MANUAL
FIRST PERSON VIEW (FPV)
ALTA 8 and SYNAPSE can power a variety of first person view (FPV) cameras and
transmitters, as well as add informational on-screen display (OSD) elements to aid
in FPV flying. Each supplied cable has the one side with a connector that mates with
a cable located in the closeout panel between booms 1 & 2.
Three FPV transmitter cables are included. The cable with two connectors on one of
the ends will run ImmersionRC and Fat Shark transmitters, the cable with a single
large connector on the end will run Boscam and transmitters, and the cable with a
single small connector will run compact Boscam transmitters.
A single camera cable is provided, and is configured to run a Ready Made RC
camera.
Camera and transmitter cables follow this wiring scheme:
CABLE COLOR FUNCTION
Red +12 VDC
Black Ground
Yellow Video signal
WARNING
It is the responsibility of the pilot to see and avoid other aircraft,
people or obstacles. Always maintain direct line of sight with
ALTA 8 during flight, use visual observers as operations require,
and follow local regulations regarding see-and-avoid requirements.
CAUTION
Do not short the pins of the FPV transmitter connector located
on the FPV transmitter lead in the ALTA 8. Doing so could
damage the on-screen display circuit. If using a multimeter to
check the pins, first connect one of the provided transmitter
cables, then take voltage readings from the transmitter cable.
