59| AIRCRAFT FLIGHT MANUAL
4. Remove the side closeout panel with the FPV
transmitter lead using the 2.0mm hex driver
5. Pass transmitter cable through the underside of the hinge, and
connect to the FPV transmitter lead
6. Replace side closeout panel
7. Zip tie the FPV transmitter lead to the boom cable bundle for strain relief
