20
11Frame
21Upright
3
1 Book Holder
41Console
51Rail
61Adjustment Handle
71Left Handlebar
81Backrest
91Seat
10 2 Seat Pulse Grip/Wire
11 1 Seat Handlebar
12 1 Spring Block
13 1 Left Shield
14 1 Right Shield
15 1 Front Stabilizer
16 1 Rear Stabilizer
17 2 Wheel
18 2 Plastic Pad
19 2 Leveling Foot
20 1 Right Handlebar
21 1 Right Pedal/Strap
22 1 Left Pedal/Strap
23 1 Right Crank Arm
24 1 Left Crank Arm
25 4 M6 x 38mm Button Screw
26 1 Pivot Block
27 1 Handle Bracket
28 1 Large Snap Ring
29 1 Pulley
30 2 Magnet
31 1 Crank
32 1 Steel Washer
33 2 Crank Bearing
34 1 Flywheel
35 1 Flywheel Axle
36 1 Resistance Magnet
37 1 Resistance Motor
38 1 Motor Bracket
39 1 Idler
40 1 Front Rail Bracket
41 1 Seat Carriage
42 1 Upper Pulse Wire
43 1 Main Wire Harness
44 1 Rear Rail Bracket
45 1 Clamp
46 1 Reed Switch/Wire
47 1 Drive Belt
4
8 4 Stabilizer Cap
49 2 Upright Grip
50 2 Flange Screw
51 1 Power Adapter/Wire
52 2 Backrest Tube
53 1 Resistance Rod Assembly
54 2 Small Spring
55 6 Carriage Bearing
56 1 Seat Rail Cap
57 4 Plastic Roller
58 1 Lower Pulse Wire
59 6 Carriage Spacer
60 2 Rail Rod
61 1 M6 x 14.67mm Shoulder Screw
62 4 Rod Cap
63 1 6.35mm x 34mm Clevis Pin
64 1 Upright Cap
65 4 M10 x 96mm Button Bolt
66 2 Wheel Bolt
67 8 M8 x 18mm Patch Screw
68 1 Large M6 Washer
69 1 Resistance Rod Lock
70 2 M8 x 68mm Button Bolt
71 4 M6 x 16mm Patch Screw
72 2 M8 x 35mm Button Bolt
73 8 M4 x 10mm Self-tapping Screw
74 10 M8 x 30mm Button Bolt
75 2 M4 x 19mm Tek Screw
76 6 M8 x 16mm x 1.5mm Washer
77 26 M4 x 16mm Screw
78 4 M8 x 16mm Button Bolt
79 1 Bright M4 x 16mm Button Screw
80 4 Rail Bolt
81 1 6.35mm x 38mm Clevis Pin
82 1 M12 x 52mm Button Screw
83 1 9.5mm x 28.5mm Clevis Pin
84 1 6.35mm x 27mm Clevis Pin
85 2 Spring Screw
86 2 M8 Curved Washer
87 1 M5 x 7mm Screw
88 8 M6 Washer
89 2 M4 x 38mm Screw
90 1 M6 Locknut
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. SFEX13809.0 R1013A
