38. Select PROG.MIX4 from the radio menu.
Set the mix for AILE to AUX2. Make sure
that the rates are both at -100% and that
the switch is set to ON. There should be
no offset for this mix.
39. On LOW RATES the Ailerons should
move 1/2" in both directions. The Thrust
Vector units should move in the same
direction as the Ailerons.
NOTE: When the Ailerons are in their neutral
position the Thrust Vector Nozzles should be
in their neutral positions also. If they are not
you must adjust them mechanically by
screwing or unscrewing the ball link connector
to achieve a neutral position.
40. On HIGH RATES the Ailerons should
move 3/4" in both directions.
41. On LOW RATES the Elevators should
move 1/2" in both directions. When the
Elevators moves UP both thrust vector
units should move up.
