08/30/96
f260369
1
2
3
4
5
6
7
8
9
10
11
12
15
13
14
1. Transmission Housing
2. Transmission Oil Pan Gasket
3. 5/16–18 Washer-Head
Capscrew
4. Plug
5. Transmission Oil Pan
6. Magnet
7. Drain Plug Gasket
8. Drain Plug
9. 5/16–18 x 5/8 Capscrew
10. Flatwasher
11. Transmission Oil Filter
12. Oil-Filter Spacer
13. O-Ring
14. Oil-Filter Tube
15. Plug
Fig. 8, Allison MT Series Transmission, Filter Removal
Transmission 26
Business Class Trucks Maintenance Manual, February 2003 26/11
