freightliner PT126SLP - Page 147

09/16/2009 f490354
1
2
3
4
5
6
7
8
9
10
11
1. DPF Inlet Temperature Sensor
2. DOC Inlet Temperature Sensor
3. DOC Inlet Pressure Sensor
4. DPF Sensor Box
5. DPF Outlet Pressure Sensor
6. DPF Outlet Temperature
Sensor
7. DPF Outlet NOx Sensor
8. SCR Inlet Temperature Sensor
9. SCR Outlet Temperature
Sensor
10. SCR Sensor Box
11. SCR Outlet NOx Sensor
Fig. 3, 2HV Two-Box ATS Sensor Locations
Exhaust 49
New Cascadia Maintenance Manual, January 2021 49/5
