S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 40 COMMUNICATIONS SETUP
ISN Address Description of Data Value Code
P62-OC07 Stop/Force Unload Status 0 = Not stopping or forcing unload
1 = Stop Load - High Motor Amps
2 = Stop Load - High Discharge Pressure
3 = Stop Load - High Discharge Temperature
4 = Stop Load - Low Suction Pressure
5 = Stop Load - High Suction Pressure
6 = Stop Load - Low Process Temperature
7 = Force Unload - High Motor Amps
8 = Force Unload - High Discharge Pressure
9 = Force Unload - High Discharge Temperature
10 = Force Unload - Low Suction Pressure
11 = Force Unload - High Suction Pressure
12 = Force Unload - Low Process Temperature
13 = Stop Load - Low Oil Flow
14 = Force Unload - Low Oil Flow
15 = Force Unload - VI OverRide
16 = At Maximum Load
17 = Stop Load - Separator Velocity
18 = Force Unload - Separator Velocity
19 = Force Unload - Stopping
20 = Stop Load - Low RPM
21 = Force Unload - Low RPM
22 = Stop Load - High Manifold Pressure
23 = Force Unload - High Manifold Pressure
24 = Warm-up Load Inhibit
25 = Slide Valve Pulldown
P63-OC08 Alarm Code (1)
P64-OC09 Alarm Code (2)
P65-OC10 Alarm Code (3)
ISN Address Description of Data
P66-A26 Current Ca
p
acit
y
Control set
p
oint
P67-A27 Current U
pp
er
p
ro
p
ortional band
P68-A28 Current Lower
p
ro
p
ortional band
P69-A29 Current U
pp
er dead band
P70-A30 Current Lower dead band
P71-A31 Process Tem
p
erature mode Sto
p
Load
(
Onl
y
p
rocess Tem
p
erature
)
P72-A32 Process Tem
p
erature mode Force Unload
(
Onl
y
p
rocess Tem
p
erature
)
P73-A33 Process Tem
p
erature mode low Tem
p
erature alarm
(
Onl
y
p
rocess Tem
p
erature
)
P74-A34 Process Tem
p
erature mode low Tem
p
erature shutdown
(
Onl
y
p
rocess Tem
p
erature
)
P75-A35 Current mode Low Suction Press. Sto
p
Load
P76-A36 Current mode Low Suction Press. Force Unload
P77-A37 Current mode Low Suction Press. Alarm
P78-A38 Current mode Low Suction Press. Shutdown
P79-A39 SPARE
