S90-010 CS (APR 08) FRICK
®
QUANTUM™ COMPRESSOR CONTROL PANEL
Page 64 COMMUNICATIONS SETUP
SETTINGS – CONTINUED
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
1117 N23:62 41118 X Analo
g
Auxiliar
y
enable/disable
1118 N23:63 41119 X Enterin
g
Process enable/disable
1119 N23:64 41120 X Slide Valve Position Control enabled/disabled
1120 N23:65 41121 X Remote Set
p
oint enable/disable
POWER FAIL:
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
1121 N23:66 41122 Power Fail Suction Pressure
1122 N23:67 41123 Power Fail Suction Tem
p
erature
1123 N23:68 41124 Power Fail Dischar
g
e Pressure
1124 N23:69 41125 Power Fail Dischar
g
e Tem
p
erature
1125 N23:70 41126 Power Fail Oil Pressure
1126 N23:71 41127 Power Fail Oil Tem
p
erature
1127 N23:72 41128 Power Fail Oil Filter Pressure
1128 N23:73 41129 Power Fail Se
p
arator Tem
p
erature
1129 N23:74 41130 Power Fail Balance Piston Pressure
1130 N23:75 41131 Power Fail Process Tem
p
erature
1131 N23:76 41132 Power Fail Slide Valve Position
1132 N23:77 41133 Power Fail Slide Sto
p
Position
1133 N23:78 41134 Power Fail Sto
p
/Force Unload
1134 N23:79 41135 Power Fail Motor Current
1135 N23:80 41136 Power Fail Rec
y
cle dela
y
SETTINGS – CONTINUED
Frick
®
Address
AB
Address
Modbus
Address
Read
Only
Description of Data
1136 N23:81 41137 Locked Rotor Current
1137 N23:82 41138 Jam Current Level
1138 N23:83 41139 DBS Service Factor
1139 N23:84 41140 Current Unbalance Alarm
1140 N23:85 41141 RTD Tem
p
erature Alarm
1141 N23:86 41142 RTD Tem
p
erature Tri
p
1142 N23:87 41143 Jam Current Level Dela
y
1143 N23:88 41144 Current Unbalance Alarm Dela
y
1144 N23:89 41145 Trendin
g
E2 Interval
1145 N23:90 41146 Trendin
g
RAM Interval
1146 N23:91 41147 Se
p
arator Velocit
y
Reference
1147 N23:92 41148 Se
p
arator Velocit
y
Reference Com
p
ression Ratio
1148 N23:93 41149 Startin
g
Dischar
g
e Pressure
1149 N23:94 41150 Hi
g
h Vi Set
p
oint
1150 N23:95 41151 Low Vi Set
p
oint
1151 N23:96 41152 Permissive Start
(
0=Disabled 1=Alwa
y
s Active 2=Startin
g)
1152 N23:97 41153 Yor
k
-S7 Set
p
oint
1153 N23:98 41154 Yor
k
-S7 Pro
p
ortional Band
1154 N23:99 41155 Slide Valve Stroke Len
g
th
1155 N23:100 41156 Oil Pum
p
Shutdown when on
1156 N23:101 41157 Oil Pum
p
Alarm when on
1157 N23:102 41158 Oil Pum
p
On
1158 N23:103 41159 Oil Pum
p
Off
1159 N23:104 41160 Economizer on
1160 N23:105 41161 Economizer off
1161 N23:106 41162 VI Deadband
1162 N23:107 41163 Oil Pum
p
Shutdown when off
1163 N23:108 41164 Oil Pum
p
Alarm when off
1164 N23:109 41165 Com
p
ressor Sto
pp
in
g
Period
1165 N23:110 41166 En
g
ine/Motor Warm u
p
time
1166 N23:111 41167 X Main Oil In
j
ection Safeties
1167 N23:112 41168 En
g
ine Confirmed RPM runnin
g
1168 N23:113 41169 En
g
ine Start dela
y
1169 N23:114 41170 En
g
ine Low RPM Sto
p
Load
