7
Amber light flashes…
● When the chime battery is low, an amber light will flash every 5 seconds. Fit new batteries in the
chime, type LR6 ‘AA’ cells. Only use alkaline batteries.
Chime/Push does not work with my older Libra equipment…
● Libra + is not compatible with the earlier Libra system.
● Only use accessories marked Libra +.
Troubleshooting cont....
SPECIFICATIONS
Specification Chime Bell push
Operating Temperature 0 to 40ºC -10 to 40ºC
RF Frequency – UK/Europe 868MHz 868MHz
Range (open Field) 100 metres 100 metres
Sound Level (typical) 80dBA @ 1m -
RF Power - <10mW
Battery Type LR6 CR2032
Battery Life (5 activations/day) 12 months 18 months
IP Rating IP3x IP55
