MEDIUM CHASSIS "M" SERIES PARTS LIST
* PARTS NOT SHOWN
MEDIUM CHASSIS 208/230 VOLT - 2006
REF DESCRIPTION PART NO# EM 230 KM 230 RM 230 SM 230 YM 230 CODE
CHASSIS PARTS
EM18L34-A EM24L35-A
KM18L30-A KM21L30-A KM24L30-A RM18L30-A RM24L30-A
SM18L30A-A
SM21L30-B
SM24L30-A YM18L34-A
12 SHROUD, CONDENSER 61804901 1111111111 1 720
13 FAN BLADE, COND. 60542004 1111111111 1 710
14 BLOWER WHEEL, EVAP. 60610617 111111 700
14 BLOWER WHEEL, EVAP. 60610618 1 1 1 1 1 700
15 BRACE, COND.SHROUD 61802600 3333333333 3 722
16 SCROLL 61817505 1111111111 1 743
17 BLOWER FRONT 61817400 1111111111 1 742
25 BRACKET, HTR 61818900 1 1 1 730
27 BASE PAN 61809005 1 1 1 730
27 BASE PAN 61803411 11111111 730
* BELLOWS, DRAIN VALVE 60179903 1 1 801
* DRAIN PAN, EVAP. 61803800 1111111111 1 840
* GRILLE, REAR 61818501 1 1 771
* GRILLE, REAR 61818801 1 1111111 1 771
28 DOOR, SLIDE ASY 61821500 1111111111 1 810
* CONNECTOR SLIDE ASY 61814800 1111111111 1 811
* WIRE CLIP, SLIDE ASSY 60301800 1111111111 1 999
29 PANEL, CTRL. MOUNT 61811050 1111111 1 999
29 PANEL, CTRL. MOUNT 61811051 1 999
29 PANEL, CTRL. MOUNT 61811001 1 1 999
32 DECORATIVE PANEL 61823300 1 1 999
32 DECORATIVE PANEL 61822600 11111 999
33 KNOBS, CRTL. 61493905 2222222 2 761
* BRACKET,RESISTOR BLK 61820600 1111111 1 999
* HOLDER, THERMISTOR 61925001 111 764
* HOLDER, AIR FILTER 61823000 2222222222 2 756
* FILTER, AIR 60865809 1111111111 1 754
* CLAMP, SUPPLY CORD 91500308 1 999
* CLAMP, SUPPLY CORD 91500307 1 1 999
* CLAMP, SUPPLY CORD 91500305 1111111 999
* CLAMP, SUPPLY CORD 91500306 1 999
34 GROMMET, COMP. 61028900 3 3333333 3 790
34 GROMMET, COMP. 01150934 3 3 790
35 SCREW, COMP. 91400400
3333333333 3 999
23 MOUNT, FAN MOTOR 61804100 1111111111 1 900
