PORTABLE "Q" SERIES
* PARTS NOT SHOWN
REF DESCRIPTION PART NO# CODE
CHASSIS PARTS
XQ05L10-B
XQ06L10-B
XQ08L10-B
XQ10L10-C
XQ12L10-D
EQ08L11-A
YQ07L10-A
16 SHROUD, CONDENSER 61627601 1111111720
17 FAN BLADE 61634000 1 710
17 FAN BLADE 61634001 1111 11710
18 BLOWER WHEEL 60610604 1 700
18 BLOWER WHEEL 60610606 1 1 1 700
18 BLOWER WHEEL 60610612 1 1 1 700
20 COVER BLOWER 61619503 1111 11745
20 COVER BLOWER 61619509 1 745
21 WRAPPER, SCROLL, 61990605 1111111741
22 FRONT, BLOWER 61928801 1 742
22 FRONT, BLOWER 61990700 11111 1742
23 DECK, BLOWER 61619405 1 745
23 DECK, BLOWER 61990500 11111 1745
28 BASE PAN 61626302 111 1730
28 BASE PAN 61626303 1 1 730
28 BASE PAN 61626304 1 730
29 COVER, UNIT TOP 61619503 1111111746
30 DRAIN PAN, EVAP. 61638400 1111111840
32 INNER WALL 61597315 11111 777
32 INNER WALL 61597316 1 777
32 INNER WALL 61597318 1 777
33 FAN MOTOR MOUNT 61776900 1 900
33 FAN MOTOR MOUNT 61776903 1111 11900
* SCREW, FAN MTR. MT. 21004672 4444444999
34 CONTROL MT. BRACKET 61619612 1 1 763
34 CONTROL MT. BRACKET 61923900 11111 763
