AVAILABLE ACCESSORIES
Unit
Model DepthHeight Width
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Thru-the-wall
Finished Hole
Uni-Fit
®
Height Width Max. Depth
USC Sleeve –
1
/
2 "15
1
/
2 " 25
7
/
8 " 16
3
/
4 " 20
1
/
2 " 15
3
/
4 " 26
1
/
8 " 16
1
/
4 "
UCT, UET Chassis
14
1
/
2 "
24
1
/
4 " -
20
5
/
16 "
– – – –
3
3
/
4 "
SLEEVE/ CHASSIS DIMENSIONS
USC SLEEVE
An existing or new sleeve is required for installation. The Friedrich USC sleeve ships with the accessories needed for installation in new
construction, or installation into an existing sleeve.
INCLUDED WITH USC SLEEVE
USC wall sleeve ships with weather
panels (2) and grille. Sleeve is shown
at right with:
IMPORTANT:
When installing into an existing sleeve, consult Installation
Section of your Installation/Operation Manual to determine
adapter (included with chassis) should be used.
Inner weather panelUSC sleeve
Outer weather panel
Standard grille
1. Painted steel inner panel
2. Painted steel outer panel
3. Painted steel standard grille
OPTIONAL GRILLE
ARCHITECTURAL GRILLE-UXAA
Optional extruded brushed aluminum grille.
UXAA, optional architectural grille
