14
Window locking
bracket
12
Fig. 9
Fig. 10
Fig. 11
12. Attach the Window Locking Bracket with a Type C
screw . (See Fig. 9)
13. Attach the front grille to the cabinet by inserting the
tabs on the grille into the tabs on the front of the
cabinet. Push the grille in until it snaps into place. (See
Fig. 10)
14. Pull down the inlet grille and secure it with a Type A
screw through the front grille. (See Fig. 11)
15. Window installation of room air conditioner is now
completed. See ELECTRICAL DATA for
inserting power cord to electrical outlet.
