Friedrich CP18 - Chassis Preparation; Chassis Preparation Steps

4
4
4
10
3
3.
Bottom
4
Fig.4-2Fig.4-1 Fig.4-3
Bottom View
Front
Fig.4-4
Front Front
and bottom
of window frame.
Bottom
4a. Make sure the pins on the bottom frame
guide are facing the back of the unit.(Fig.4-1)
4b. Align both pins to the slotted areas under
the cabinet.(Fig.4-2,Fig.4-3)
4c. Push upward fully to insert pins into slotted
areas and secure frame guide.(Fig.4-4)
