28
4.Put wiring cover back and then tighten the screw.
5.Close the panel.
Installation of indoor unit
Note:
● All wiring should be done by a certified technician.
for a new one. Avoid extending the wire by yourself.
installation.
● For the air conditioner without plug, an circuit break must be installed in the line.
The circuit break should be all-pole parting and the contact parting distance
should be more than 3mm.
3. Remove wire strain relief. Connect each wire to the corresponding terminal.
Tighten the terminals to ensure solid connections.
power connection
wire
cable-cross
hole
2. Ensure that power wires are routed through
the proper opening behind the unit.
Outdoor unit connection
green
green)
red
black
(yellow-
(brown)
white
(blue)
2 3N(1)
18K
24K :
09K
12K
