SPECIFICATIONS
Refrigeration Systems Performance Data
Model
Condensor
Temp
Deg F.
Discharge
Temp
Deg. F
Suction
Temp
Deg F
Electrical Ratings
R-410A
REF. Breaker
AMPS
COOL
AMPS
HEAT
LOCKED
ROTOR
AMPS
CHARGE
IN OZ Voltage
60
HERTZ
AMPS
Kühl
®
(Cool Only)
KCS08A10A 111 154 59 6.5 30.5 24.5
115 15
KCS10A10A 114 155 56 8.5 49 32 115 15
KCS12A10A 118 159 54 9.5 52 33 115 15
KCS12A30A-A 117 170 69 4.8 29 35.9 230 15
KCS12A30A-B 117 170 69 4.8 29 35.5 230 15
KCS12A30A-C 117 170 69 4.8 29 35.9 230 15
KCS12A30A-D 117 170 69 4.8 29 27.7
230 15
KCS14A10A-C 120 169 57 11.8 54.5 26 115 15
KCS14A10A-D 120 169 57 11.8 54.5 25
115 15
KCS16A30A-(A THRU D) 121 163 45 6.6 33 38.3 230 15
KCS16A30A-E 121 163 45 6.6 33 31
230 15
KCM14A10A 113 147 49 10.9 54.5 38
115 15
KCM18A30A 119 180 61 9.6 46 46
230 15
KCM21A30A 123 171 53 9.6 46 46 230 15
KCL24A30A
KCL24A30B
122 168 55 11.1 52
46
230 20
43
KCL28A30A-A, -C, -D 126 167 45 13.4 60 58.5 230 20
KCL28A30A-A, -C, -D 126 167 45 13.4 60 51.2
230 20
KCL36A30A 130 179 44 18.2 76 68
230 30
Kühl
®
+ (Heat Pump)
KHS10A10A-A 116 153 54 8.8 9.1 50 28.5
115 15
KHS10A10A-B, -C 25.6 115
KHS12A33A 120 163 53 5 4.7 29 28
230 20
KHM18A34A 117 160 52 7.4 7.4 37 43.1 230 30
KHL24A35A 122 175 64 11.1 10.3 52 48
230 30
Kühl
®
+ (Electric Heat)
KES12A33A 117 170 69 4.9 29 33 230 20
KES16A33A-(A THRU D) 121 163 45 6.6 33 38.3 230 20
KES16A33A-E 121 163 45 6.6 33 31 230 20
KEM18A34A 119 180 61 9.6 46 230 30
KEL24A35A
KEL24A35B
122 168 55 11.1 52
46
230 30
43
KEL36A35A 130 179 44 18.2 76 68
230 30
*Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp &
40% relative humidity, all systems use R-410A. Test done at highest unit fan speed.
Figure 201 (Refrigeration Systems Performance Data)

Friedrich KHS10A10A Specifications

General

Brand	Friedrich
Model	KHS10A10A
Category	Air Conditioner
Language	English
