7. SERVICE PARTS LIST
• KP05A10, KP06A10
130410 BASE ASSEMBLY,SINGLE 3041A10011F 67302906 R
130910 CABINET ASSEMBLY,SINGLE 3091A10020A 67303704 R
135312 GRILLE ASSEMBLY,FRONT(SINGLE) 3531A10130D R
135303 GRILLE,INLET 3530A10157A R
135500 COVER 3550A30048A 3550U-L006A 67301202 R
145200 LINK 4520AR3191A 67304600 R
159900-1 VANE,VERTICAL 5990AR3190A 67304500 R
159900-2 VANE,VERTICAL 5990AR3190B 67304501 R
148000 BRACE 4800A30003A R
149980 SHROUD 4998A10008A 67303106 R
152302 FILTER(MECH),A/C 5231AR2148G 67400167 R
249950 CONTROL BOX ASSEMBLY,SINGLE 4995A20309A R
264110 POWER CORD ASSEMBLY 2H00677P 67300000 R
267110 REMOTE CONTROLLER ASSEMBLY 6711A20056V R
263230 THERMISTOR ASSEMBLY 6323A20003D R
268712 PWB(PCB) ASSEMBLY,DISPLAY 6871A20193B R
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10070N R
346811 MOTOR ASSEMBLY,SINGLE 4681A10002R 4681A10012M R
349480 ORIFICE 4948A10007A 67303405 R
352113 TUBE,DISCHARGE 5210A21100A 5211A10129A 67302306 R
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10063C 67302005 R
35211A TUBE ASSEMBLY,SUCTION SINGLE 5211A10062B 5211A10062D R
352390-1 AIR GUIDE ASSEMBLY 5239A10005B R
352390-2 AIR GUIDE ASSEMBLY 5239A30003A 67302707 R
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20016G 67302407 R
359012 FAN,TURBO 5900A10005A 67302606 R
550140 ISOLATOR,COMP 5040AR4195A 67301900 R
552102 TUBE,CAPILLARY BEND 5210A30018K 5210A30018P R
554030 CONDENSER ASSEMBLY,FIRST 5403A20009E 5403A20009F R
554160 COMPRESSOR 5416A20014D 2520UABC2JA 67301607 R
559011 FAN,PROPELLER 5900A20017A 67303205 R
567502 O.L.P 6750A30001U 6750U-L050A R
W0CZZ CAPACITOR,DRAWING 6120AR2359V R
W48602 CLAMP,SPRING 3H02932B R
132111-1 FRAME ASSEMBLY 3211AR3239A R
132111-2 FRAME ASSEMBLY 3211AR3239B R
352111 TUBE ASSEMBLY,FORMED COND 5211AR3399M R
PART NO. FRIEDRICH PART NO.
KP05A10 KP06A10 KP05A10 KP06A10
LOCATION
NO.
Remark
DESCRIPTION
To Next Page
