OUTDOOR UNIT
Ref. Part No. Ord.
No MR24UY3F Q'ty
1 Top Panel Sub Assy 67201640
2 Front Panel 67201601
3 Fan Guard 67201602
4 Grip Side 67201603
5 Service Panel Sub Assy 67201688
6 Right Panel 67201605
8 Propeller Fan Assy 67201607
9 Motor, Induction 67201608
10 Condenser-A Assy 67201609
11 CoilChoke 67201633
12 Strainer Assy 67201611
13 Separate Wall Assy 67201647
14 Cap Foot 67201650
15 Base Assy 67201648
17 3-Way Valve Assy (3/8) 67201614
18 3-Way Valve Assy (5/8) 67201615
19 Check Joint Assy 67201616
20 CompressorAssy 67201689
22 4-Way Valve 67201619
23 Solenoid 67201681
24 Pressure Switch 67201621
25 Inlet Pipe Cond A Assy 67201622
26 Inlet Pipe Cond B Assy 67201690
27 Outlet Pipe Cond A Assy 67201691
28 Expansion Valve Assy 67201692
29 Coil (Expansion Valve) 67201422
30 Distributor 67201693
31 Discharge Pipe A Assy 67201694
33 Terminal2P 67220181
34 Terminal5P 67201632
35 ACTPM 67201627
36 Holder Thermo 67201628
37 Inverter PCB Assy 67201695
38 Power PCB Assy 67201696
---- Fuse 3.15A-250V 67201697
---- Thermistor (Outdoor Temp.) 67201686
---- Heat Exchanger Thermistor 67201698
---- Thermistor (Discharge) 67201635
---- Compressor Thermistor 67201637
---- Thermistor 67201430
---- Heatsink Thermistor 67201685
---- Transformer 67201699
---- Varistor 67201700
---- Arrester 67201701
---- Relay 67201702
---- Relay 67201703
---- Switch Push 67201704
---- Switch Slide 67201705
---- Drain Pipe Assy 67201706
---- Drain Cap 67201707
2006.05.25 22
