Page #5 background imageLoading...
Page #5 background image
Evaporator
OUTDOOR UNIT
Pressure
Check Valve
Condenser
4-way
Valve
High Pressure
Switch
Accumulator
Muffler
Compressor
Expansion
Valve
Refrigerant Pipe
9.52mm (3/8")
Charging Valve
Charging
Valve
Refrigerant Pipe
15.88mm (5/8")
INDOOR UNIT
Strainer
Strainer
REFRIGERANT SYSTEM DIAGRAM
: COOL
: HEAT
2006.05.18 4
