Friedrich MR18C3E - Page 39

2003.06.19 - 38 -
MR30C3E
Reference No.
Description
Part No.
2 Fan Cover 67210040
4 Emblem-Rear ”FRIEDRICH” -------
6 Cabinet-C, Painted 67210039
7 Panel (Top), Painted Metal -------
9 Cabinet-B, Painted 67210038
12 Base Assy. Painted 67210036
13 3-Way Valve Assy. ------
14 2-Way Valve Assy. ------
15 Dryer 67210033
16 Condenser Assy. 67210035
19 Capillary Tube 67230047
519 Restrictor Valve (Cap Tub) ------
519 Restrictor Valve (Cap Tub) ------
26 Compressor Cover ------
30 Blower Cover 67210040
34 Capacitor(Fan Motor) 67230046
37 Running Capacitor 67230047
39 Propeller Fan Assy. 67210034
41 Fan Motor Assy.-OUT 67210053
46 Compressor Assy. 67210050
218-3 Power Relay 67210044
272 Strainer ------
343 Solenoid Coil ------
344 4-Way Valve ------
519 Check Valve Assy. ------
549 Thermostat – Outdoor 67210054
646 Compressor Cover-B ------
717 Center Plate ------
734 Cabinet Tip Plate 67210042
803 Cabinet D Painted 67210048
805 Blower Cover Corner 67210041
809 Ball Valve A 67210003
810 Ball Valve B 67210004
815 Terminal-8P 67210032
824 Fuse
Q1 Xstr 2SC4236 67220089
T1 Transformer ETS28A118AH 67210028
BZ1 Buzzer 67220050
13m 3 (6,& Relay JQ1-12V 67210023
SSR-1 Relay G3M-202P-US 67210024
F101 Fuse MT3 3A-250V 67210000
PARTS LIST
