When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
1 Top Panel Assy 9309230057
2 Top Panel Seal 9309228016
3 Cabinet Sub Assy 9314809040
4 Blow Down Grille 9308884015
5 Cabinet Right Assy 9309236011
6 Fan Ring 9308885012
7 Grip 9308880017
8 Switch Cover Assy 9309237049
10 4-Way Valve 9970056017
11 Expansion Valve Assy 9311641018
12 Strainer 9311440017
13 Condenser Assy 9311382027
14 Thermistor Spring-A 313728262708
15 Thermistor Spring-A 9300089012
16 Propeller Fan 9309909014
18 Motor Bracket 9308872012
19 Separator 9312971015
20 Base Assy 9308869081
21 3-Way Valve Assy 9315159014
22 2-Way Valve Assy 9313064013
24 Cord Clamp 9307271014
25 Terminal 9703874024
26 Inverter PCB Assy 9707039085
29 Fuse 0600382018
32 Expansion Valve Coil 9900057039
34 Fan Motor 9602133017
35 Compressor Assy 9313764012
36 Emblem Rear 9312661015
37
Thermistor Assy
(Heat Exchanger & Discharge Pipe)
9900148027
Thermistor
39 Solenoid Coil 9970033025
---
41 Intelligent Power Module 9705720015
---
Outdoor Temp. Thermistor 9900210045
9900041014
Ref.
No.
Description
Part No.
MR18C3F
Ord.
Q'ty
2006.08.22 15
40 Protective Net 9315319012
To Next Page
