When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
PARTS LIST
--- Indicator PCB Assy 9705039032
Evaporator B Assy 9311275022
1 Air Filter 9309997011
2 Filter (Electric + ION) 9312152018
5
4
Clamper (Grille) 9306755010
6
Front Panel
9309999053
7 Intake Grille Assy 9313566036
24 Crossflow Fan Assy 9307836015
37 Insulation (Pipe)-E 9304607007
38 Holder (Evaporator)-L Assy 9313174019
39 Holder (Evaporator)-R 9309983014
40 Water Seal 9312912018
43 Terminal 9701955114
46 Step Motor 9900139025
48 Fan Motor Assy 9602109012
51 Remote Control Unit 9315027061
52 Bracket Panel 9310001004
61-1
Flow Control Panel-U
9309991033
61-2 Flow Control Panel-Z 9309992030
236 Controller PCB Assy 9707193022
--- Pipe Temperature Thermistor 9702039042
---
---
Room Temperature Thermistor
9700801108
Holder (Filter) 9306602017
20 Gear-A 9309994003
21
Casing Assy
9311354079
26 Clamp (Motor) 9313724016
27 Shaft Holder-C Assy 9306628017
28 Drain Hose Assy 9314147012
29 Drain Cap Assy 9314493010
30 Wire Clamper 9313944018
32 Cover (Switch) 9313943011
33 Evaporator Total Assy 9313099015
36 Joint Pipe Assy 9313792015
(K04CP-0504WSE-C1)
Ref.
No.
Description
Part No.
MW18C3F
Ord.
Q'ty
2006.06.08 14
31 Holder (Room Thermistor) 9311948018
To Next Page
