Thank you for your decision to purchase the newly designed Friedrich Packaged Terminal Air Conditioner (PTAC). We are
confi dent that you will fi nd this unit a quiet and effi cient example of Friedrich reliability.
This Installation and Operation Manual has been designed to insure maximum satisfaction in the performance of your
unit. For years of trouble-free service, please follow the installation instructions closely. We cannot overemphasize the
importance of proper installation. We have added new information to the basic instructions to help you achieve success.
Remember, proper installation is not diffi cult but it is essential.
Please read this manual thoroughly prior to equipment installation or operation. It is the installer’s responsibility
to properly apply and install the equipment. Installation must be in conformance with the NFPA 70-2008 National
Electric Code or current edition and Uniform Mechanical Code current edition and applicable local or national codes.
Failiure to do so can result in property damage, personal injury and/or death.
Model Number Code
PD H 07 K 3 S B 1
Engineering Digit
Design Series
Chassis
S = Standard
Note: All PTAC models with a C design series
or later come standard with Diamonblue
seacoast protection and digital controls.
Nominal Heater Size (@ 230V or 265V)
0 = No Heater (only on PDE09K, PDE12K AND PDE15K)
2 = 2.5 KW* 3 = 3.4 KW 5 = 5.0 KW**
* 2.5 kw only available on 7000, 9000, and 12000 BTU models
** 5.0 kw only available on 12000 and 15000 BTU models
Voltage
K = 230/208V - 1 Ph. - 60 Hz.
R = 265V - 1 Ph. - 60 Hz.
Series
PD = Friedrich Digital PTAC
System
X = Accessory
E = Cooling with or without electric heat
H = Heat Pump with Auxiliary Heat
07 = 7,000 Btuh
09 = 9,000 Btuh
Nominal Cooling Capacity
12 = 12,000 Btuh
15 = 15,000 Btuh
