Thank you for your decision to purchase the newly designed Friedrich Packaged Terminal Air Conditioner (PTAC). We are
confident that you will find this unit a quiet and efficient example of Friedrich reliability.
This Installation and Operation Manual has been designed to insure maximum satisfaction in the performance of your unit.
For years of trouble-free service, please follow the installation instructions closely. We cannot overemphasize the importance
of proper installation. We have added new information to the basic instructions to help you achieve success.
Remember, proper installation is not difficult but it is essential.
I
Series
PD = Friedrich Digital PTAC
System
X = Accessory
E = Cooling with orwithout
electric heat
H = Heat Pump with Auxiliary Heat
Nominal Cooling Capacity
07 = 7,000 Btuh
09 = 9,000 Btuh
12 = 12,000 Btuh
15 = 15,000 Btuh
Model NumberCode
PDH 07K 3 S A 1
I_
t Engineering Digit
I Design Series
Options
S = Standard
C = Seacoast Protection
Nominal Heater Size
(@ 230V or 265V)
0 = No Heater 3 = 3.4 KW
2 = 2.5 KW 5 = 5.0 KW*
* 5.0 kw onlyavailable on 12000and 15000
Btu/h models
I
Voltage
K = 230/208V - 1 Ph, - 60 Hz.
R = 265V-1 Ph.-60Hz,
I
I
I
I
Please read this manual thoroughly prior to equipment installation or operation. It is the installer's responsibility
to properly apply and install the equipment. Installation must be in conformance with the NFPA 70-2002 National
Electric Code or current edition and Uniform Mechanical Code current edition and applicable local or national codes.
