—29—
5. SCHEMATIC DIAGRAM
5.1 CIRCUIT DIAGRAM
• MODEL : US08A10A/US10A10A/US12A10A/US10A30A/US12A30A
1
3
7
4
2
6
5
MOTOR
COMP.
BR(YL)
P.T.C
WIRING DIAGRAM 3854AR3563A
GN(GN/YL)
LOCATION
NO.
1
2
3
4
5
6
7
Q'TY
PER SET
1
1
1
1
1
1
1
RE-
MARKS
DESCRIPTION
POWER CORD
ROTARY SWITCH
FAN MOTOR
CAPACITOR
THERMOSTAT
COMPRESSOR
OVERLOAD PROTECTOR
US08A10A US10A10A US12A10A US10A30A US12A30A
2H00677R 2H00677S 2H00677G
2H00598E
4681A20044G 4681A20044F 4681A20041D 4681A20044E 4681A20041C
6120AR2194P 6120AR2194K 2A00986Y 6120AR2194D
2H01109M
2520UAFC2AC 2520UKC2AC 2520UKGC2DA 2520UKCK2BA 2520UKHK2CA
6750U-L005A 6750U-L031A 6750U-L004A 6750U-L028A 6750U-058A
PART NO.
