—33—
A 249950 CONTROL BOX ASSY, SINGLE 4995A20131R R
264110 POWER CORD ASSY 2H00677G R
266003 SWITCH, ROTARY 2H00598E R
269310 THERMOSTAT ASSY 2H01109M R
W0CZZ CAPACITOR, DRAWING 6120AR2194D R
149410 KNOB ASSY 4941A30005B R
137215 PANEL ASSY, CONTROL 3721A20049E R
B 554160 COMPRESSOR 2520UKCK2BA 2520UKHK2CA R
550140 ISOLATOR, COMP 4H00982E R
567502 O.L.P 6750U-L028A 6750U-L058A R
C 352113
TUBE ASSY, DISCHARGE SINGLE
5211A30588B 5211A30588A R
352115
TUBE ASSY, EVAPORATOR IN
5211A20289C 5211A20904A R
352115-1
TUBE ASST, EVAPORATOR IN
- 5211A20904B R
35211A
TUBE ASSY, SUCTION SINGLE
5211A20498B 5211A30587A R
552111 TUBE ASSY, CAPILLARY 5211A20214L 5211A20214K R
D 352390 AIR GUIDE ASSY 5239A10002E R
349001 DAMPER VENTILATION 4900A20001A R
E 135312 GRILLE ASSY, FRONT 3531A20121A R
135313 GRILLE, INLET 3530A20053A R
147581 LOUVER, HORIZONTAL 4758A20008B R
147582-1 LOUVER, VERTICAL 4758A20009A R
147582-2 LOUVER, VERTICAL 4758A20009B R
152302 FILTER(MESH), A/C 5230A20007A R
349480 ORIFICE 4948A10006A R
149980 SHROUD 4998A10007B R
346811 MOTOR ASSY, SINGLE 4681A20044E 4681A20041C R
349600 MOUNT, MOTOR 4960A20005A 4960A20008A R
148000 BRACE 4800A30002A R
435301 GRILLE, REAR 3530A30002A R
354210 EVAPORATOR ASSY, FIRST 5421A20071E 5421A20060A R
359012 FAN, TURBO 5900A20009A R
554031 CONDENSER ASSY, BENT 5403A20040P 5403A20040H R
559010 FAN ASSY, AXIAL 5900AR1173A R
W48602 CLAMP, SPRING 3H02932B R
130410 BASE ASSY, SINGLE 3041A10014V 3041A10014T R
130900 CABINET 3090A20003B R
749180 TRIM 4918A20001A R
• MODEL: US10A30A/US12A30A
PART NO.
DESCRIPTION
REMARK
LOCATION
NO
.
US10A30A US12A30A
R: Service Parts
N: Non Service parts
To Next Page
